    50mm (Grade 3) Single Gypsy Single Drum Electric Anchor Windlass

    Ask Lasest Price
    Brand Name : Zhongyuan
    Model Number : Electric Anchor Windlass
    Certification : CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA, Makers Test Certificate, Etc.
    Price : As per quotation
    Payment Terms : TT, L/C, Etc.
    Supply Ability : Satisfy clients needs
    Delivery Time : As per offer
    • Product Details
    • Company Profile

    50mm (Grade 3) Single Gypsy Single Drum Electric Anchor Windlass

    50mm (Grade 3) Single Gypsy Single Drum Electric Anchor Windlass


    Description

    The single gypsy single drum electric anchor windlass is engineered to meet class requirements spanning anchor chain sizes from 12.5mm to 142mm. Our 50mm (Grade3) electric anchor windlass features a single gypsy, single drum and warping end, electric motor driven, manual brake, jaw clutches, hydraulic units, and an electric switchboard.

    Our hydraulic-driven configuration is available with standard or custom control consoles, hydraulic transmission device. Additionally, we provide combination mooring winches and anchor windlasses designed to accommodate all chain sizes for ships.

    This comprehensive offering ensures efficient and reliable handling of anchor operations, tailored to meet the diverse needs of maritime applications.


    Product Features:

    1. Precision Gear Design: Ensures low noise and minimal vibration through precise gear machining, providing a quieter and more comfortable operating experience.
    2. Efficient Transmission: Saves energy, reduces operating costs, and optimizes performance for efficient operation.
    3. Optimized Motor Power: Utilizes appropriate motor power and high-torque hydraulic motors to enhance overload capacity, ensuring reliable operation under demanding conditions.
    4. Quick Anchor Chain Release and Retrieval: Facilitates fast and efficient anchor chain release and retrieval, improving operational efficiency.
    5. Complete Anchor System Solutions: Offers comprehensive solutions with anchor windlasses and chain stoppers tailored to specific vessel requirements.
    6. 3D Design of Full Anchor Chain System: Ensures smooth passage of anchor chains through chain pipes and chain stoppers, optimizing operational efficiency.
    7. Simple Installation: Simplifies onboard installation with commonly available 10.9-grade anchor bolts and cost-effective steel adjustment pads.
    8. Customizable Control Console: Provides stainless steel console options with centralized displays for monitoring pressure, current, voltage, and speed, and can be equipped with an anchor chain length counter.
    9. Remote Control Capability: Supports remote operation from the bridge, enhancing convenience and operational flexibility.
    10. Enhanced Transmission Strength: Incorporates a common base design to optimize power transmission efficiency.
    11. Integrated Safety Features: Automatically triggers alarms in case of operational issues to ensure safe and reliable usage.
    12. These features and advantages enable the anchor windlass system to excel in marine applications, delivering outstanding performance, usability, and safety.

    Main Technical Specifications:

    1. Custom Engineered Units
    2. Chain Sizes 12.5mm to 142mm
    3. Designed per Class Rules
    4. Electric or Hydraulic Operation
    5. Fully Enclosed Gearbox, or half closed gearing(economical design)
    6. Fail-safe Brake
    7. Band Brake
    8. Jaw Clutch
    9. Capstan Head
    10. Control Packages
    11. Chain Stopper
    12. Surface Treatment: SA2.5 sand blasting, and marine paint.
    13. Certificate: BV, DNV, ABS, LR, IRS, RMRS, CCS, etc.

    Main Technical Parameters:

    Chain Dia.
    (mm)
    Working Load
    (kN)
    AM2 Static Load
    (kN)
    Working Speed
    (m/min)
    Warping Load
    (kN)
    Electric Motor
    Power
    (kW)
    Hydraulic Motor
    Power
    (kW)
    12.55.930≥953/1.2
    14/16/17.58.3/10.9/13.051/67/80≥984.3/1.75.5
    19/20.5/2215.3/17.9/20.695/110/126≥9108.5/3.57.5
    24/2624.5/28.7149/175≥9208.5/3.511
    28/3033.3/38.3202/231≥93011/11/7.515
    32/34/3643.5/49.1/55.1261/294/329≥93016/16/1122
    38/40/4261.4/68.0/75.0365/402/442≥94022/22/1630
    44/46/4882.3/89.9/97.9483/526/570≥95030/30/2237
    50/52/54106.3/114.9/123.9617/664/713≥95030/30/2245
    56/58/60133.3/143.0/153764/816/870≥96045/45/3055
    62/64163.4/174.1925/982≥98045/45/3055
    66/68185.1/196.51040/1098≥910045/45/3075
    70/73208.3/226.51160/1254≥910060/60/4575
    76/78245.5/258.61350/1416≥912560/60/4590
    81/84311.7/335.22171/2321≥914075/75/36110
    87/90359.5/384.82473/2629≥915075/75/36120
    92/95402.0/428.72735/2898≥920085/85/64130
    97/100446.9/475.02995/3162≥9250100/100/50150
    105/107523.7/543.83612/3750≥9300110/110/55180
    112/114595.8/617.34109/4228≥9350132/132/66200
    120/122684/7074374/4495.5≥9400 250
    124/127730.4/766.14626/4819.5≥9450 315
    130/132802.8/827.65013/5139≥9500 315
    137/142891.5/957.85472/5809.5≥9550 350
    Drawing of 50mm Horizontal Anchor Windlass Electric Single Gypsy Single Drum Windlass
