Brand Name : | Zhongyuan |
Model Number : | Standard and Customized |
Certification : | CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA, Makers Test Certificate, Etc. |
Price : | As per quotation |
Payment Terms : | TT, L/C, Etc. |
Supply Ability : | Satisfy clients needs |
Delivery Time : | As per offer |
British Standard Long Pitch Link Chain
Description:
The British standard long pitch link chain is widely used in textile machinery, clothing machinery, conveying equipment, packaging machinery, electric vehicles, food machinery, ships, mining equipment, agricultural machinery, etc. it belongs to the type of crank chain. It is a compact ring chain, which conforms to ISO DIN BS JIS GB and other standards.
Main Technical Specifications:
Main Technical Parameters:
Specification | Test Load | Breaking Load | Net wt Per 200FT(kg) | ||||
D | L | W | |||||
in | mm | mm | mm | kg | kg | B.F | H.D.G |
1/8 | 3.20 | 23 | 12 | 200 | 400 | 10.40 | 10.70 |
5/32 | 4.00 | 27 | 15 | 300 | 600 | 16.60 | 17.50 |
3/16 | 4.70 | 31 | 17 | 400 | 800 | 22.40 | 23.30 |
7/32 | 5.50 | 32 | 19 | 550 | 1100 | 32.00 | 33.00 |
1/4 | 6.35 | 33 | 21 | 750 | 1500 | 43.50 | 44.80 |
5/16 | 7.94 | 48 | 31 | 1200 | 2400 | 68.00 | 70.00 |
3/8 | 9.50 | 60 | 37 | 1700 | 3400` | 96.00 | 99.00 |
7/16 | 11.11 | 71 | 41 | 2300 | 4600 | 126.00 | 129.00 |
1/2 | 12.70 | 85 | 48.5 | 3000 | 6000 | 167.00 | 172.00 |
5/8 | 15.80 | 114 | 61.5 | 4700 | 9400 | 256.00 | 264.00 |
3/4 | 19.00 | 125 | 75 | 6800 | 13600 | 381.00 | 392.00 |
7/8 | 22.20 | 140 | 88 | 9250 | 18500 | 527.00 | 543.00 |
1 | 25.40 | 155 | 100 | 12150 | 24300 | 696.00 | 716.00 |
![]() |
