CB* 286 Cast Steel Lever Type Anchor Chain Stopper Ship Mooring Equipment
Description
CB* 286 cast steel lever type anchor chain stopper is mounted by
welding on the foundation or on the forecastle deck. The body is
made of high quality casting steel. The bar type chain stopper uses
the bar to clamp the anchor chains and prevents it from movement
during ship sailing. Counterbalance weights is alternative design
which is most suitable for larger and heavy bar to make the
operation easily by the ship crew. This type of chain stopper is
mainly used on boat and inland waterway ships. It is simple
structure and easy to operate. We can produce all types of chain
stoppers and provide customized service. For more information,
please feel free to contact us.
Main Technical Specification:
Main Technical Parameters:
Anchor Chain Diameter(mm) | B | H | L | Welding Foot f | Body Weight (kg) |
12.5-14 | 142 | 162 | 235 | 5 | 20 |
16-17.5 | 170 | 190 | 270 | 6 | 25 |
19-20.5 | 193 | 216 | 320 | 6 | 30 |
22-24 | 219 | 241 | 345 | 7 | 37 |
26-28 | 241 | 270 | 385 | 7 | 46 |
30-32 | 274 | 305 | 435 | 9 | 56 |
34-36 | 304 | 342 | 490 | 9 | 69 |
38-40 | 336 | 378 | 540 | 10 | 85 |
42-44 | 366 | 412 | 590 | 10 | 108 |
46-48 | 397 | 450 | 640 | 12 | 139 |
50-52 | 428 | 491 | 695 | 12 | 173 |
54-56 | 457 | 528 | 745 | 13 | 210 |
58-60 | 488 | 564 | 795 | 13 | 255 |
62-64 | 517 | 600 | 850 | 14 | 305 |
66-68 | 547 | 635 | 900 | 14 | 363 |
Drawings of Cb* 286 Cast Steel Lever Type Anchor Chain Stopper Ship Mooring Equipment
![]() |
