    6 Persons 4.54m GRP Fast Rescue Boat Ship Life Saving Equipment

    Ask Lasest Price
    Brand Name : Zhongyuan
    Certification : CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA, Makers Test Certificate, Etc.
    Model Number : Standard and Customized
    Price : As per quotation
    Delivery Time : As per offer
    Payment Terms : TT, L/C, Etc.
    Supply Ability : Satisfy clients needs
    • Product Details
    • Company Profile

    6 Persons 4.54m GRP Fast Rescue Boat Ship Life Saving Equipment

    6 Persons 4.54m GRP Fast Rescue Boat Ship Life Saving Equipment


    Description

    This boat are designed in accordance with the International Convention on SOLAS 1974, Amendment 1996, MSC47(66), LSA Code, MSC.226(82), MSC.218(82),MSC.272(85), MSC.320(89),MSC.321(89.). The space between the outer hull and the inner section are buoyancy tanks and filled with polyurethane hard foam.


    Main Technical Specifications:


    Classification Certificates: MED(B+D_DOC), MED(B+F+DOC), CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA, Etc.


    No.ItemDescription
    1Boat typeF.R.P. rescue boat
    Model: GJ4.5
    2DimensionOverall length 4.54m(incl. fender)
    Length(mld.) 4.50m
    Overall breadth 1.90m(incl. fender)
    Breadth(mid.) 1.86m
    Depth 0.86m
    Boat weight (no load): 775kg
    Persons weight(6P) 495kg
    Total weight (full load) 1270kg(incl.6P)
    Speed More than 6 knots (with 6P)
    Fuel oil tank capacity 50/liter
    Engine model Mercury 25HP
    Starting system Electric + hand
    Temperature - 20 - 45 ℃
    3Number of personsRescue boat:6 Persons
    4Engine and accessoriesThere is fitted an outboard gasoline engine(25Hp). There is a fuel oil tank of 50 liter for boat running four hours at the speed of over 6 knots with 6 persons.
    Two independent chargeable starting system are installed (two batteries), and a
    manually operated bilge pump is provided to drain water from boat. All the tools and spares for engine are also supplied.
    5Console

    Console is fitted at the stem at the position of helmsman. The main operation can be carried out from this place
    The following equipment are fitted on the console
    (1) Steering gear
    (2) Remote control for engine

    (3) Search light
    (4) Compass

    6Hook deviceA single point lifting arrangement is fitted and connected with boat by support. Its safety working load is 34.335KN.
    7RightingA kind of buoyant material of rigid foam is fitted at the stern, ensure that the rescue boat is capable of being righted by no more than two persons when it is inverted in the water
    8ConstructionThe main parts are laminated in independent moulds. All the materials are carefully checked and tested for laminate in order to ensure the boat to support the load in service
    The outer hull and inner hull are shaped in separate mould, then connected to shape the seats and buoyancy tank. The buoyancy tank provides sufficient buoyancy to float the boat at flooded condition with all the persons onboard
    9Electrical equipmentThe boot ore equipped with two independents chargeable batteries, a charger
    is supplied by maker. A 15m length 2X2.5 electrical cable is supplied by maker with a plug.
    AC42V electric power is supplied to rescue boot by davit. A position light is fitted on buoyancy tank. The switches for all lights ore fitted on the console.
    10Other EquipmentA painter release hook is fitted at bow. Buoyant lifelines and grips are fitted on both sides. All the equipment required by LSA Code are provided.

    Drawing of 6 Persons 4.54m GRP Fast Rescue Boat Ship Life Saving Equipment
