    JIS F 2014 Steel Plate Fabricated Rollers Open Type 3 Rollers Shipside Fairlead Ship Mooring Equipment

    Ask Lasest Price
    Brand Name : Zhongyuan
    Certification : CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA, Makers Test Certificate, Etc.
    Model Number : Standard and Customized
    Price : As per quotation
    Delivery Time : As per offer
    Payment Terms : TT, L/C, Etc.
    Supply Ability : Satisfy clients needs
    • Product Details
    • Company Profile

    JIS F 2014 Steel Plate Fabricated Rollers Open Type 3 Rollers Shipside Fairlead Ship Mooring Equipment

    JIS F 2014 Steel Plate Fabricated Rollers Open Type 3 Rollers Shipside Fairlead Ship Mooring Equipment


    Description:

    Open type CF CS fairlead roller is with high quality and stable performance. Besides, our all products are approved by IACS certificate. Meanwhile our products are produced in accordance with Japanese standard. And this kind of fairlead can bear 45mm to 100mm hemp ropes and any other ropes with different sizes. So please feel free to contact us if you are interested in any of our products.


    Main Technical Specification:

    1. Technical Standard: JIS F 2014-1987

    2. Type: CF&CS OPEN TYPE

    3. Roller Diameters: 150~450mm

    4.Roller No.: 3 Rollers

    5.Roller Weight:43.6~415kg

    6. Materials: Mild Steel, C-Mn Steel, Stainless Steel, Casting Steel, Nodular Cast Iron

    7. Surface treatment: sandblasting to S2.5 + one layer of epoxy shop primer, Galvanized, Polished, customized surface treatment available.

    8.Classification Certificates:CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, Etc.

    9.Can be Customized


    Main Technical Parameter:

    Nominal Dia.DLII1I2
    1501501160420160-
    2002001460530200-
    2502501740640230-
    3003002020750260-
    3503502300860290-
    4004002580970320-
    45045028801080360-

    ​Drawing of JIS F 2014 Steel Plate Fabricated Rollers Open Type 3 Rollers Shipside Fairlead
