    CB 3062 Type D Seven Tube Rollers Universal Fairleads with Upper Roller Ship Towing Equipment

    CB 3062 Type D Seven Tube Rollers Universal Fairleads with Upper Roller Ship Towing Equipment


    Description

    It consists 3 vertical & 4 horizontal rollers, guide ropes from 6 directions. It locates on shipside of freeboard deck. It reduces the abrasion of mooring ropes through rollers fixed around the fairlead. It can be applicable to wider range or operation angle, and better protection the steel wire rope and nylon rope. It is applicable to nylon ropes and steel wire ropes. It is used on commercial ships, Navy ships and Offshore.


    Main Technical Specification:

    1. Model Type: Type D
    2. Materials: C-Mn Steel, Mild Steel, Stainless Steel
    3. Standard: CB/T*3062-79
    4. Roller No.: 7 Rollers
    5. Steel Cable Diameters: 19.5mm~68.0mm
    6. Nylon Rope Diameters: 36mm~100mm
    7. Weight: 247kg~5100kg
    8. Surface treatment: sandblasting to S2.5 + one layer of epoxy shop primer, Polished, Galvanized, customized surface treatment available.
    9. Classification Certificates:CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA.

    Main Technical Parameter:

    Steel Rope
    Dia.
    Nylon Rope
    Dia.
    EFDdLLlL2L3BBlB2HHlWeight
    (kg)
    19.53620015010040-0.5944716300844238194108508250247
    22.54020015012050-0.51048776320928280232128552270377
    264520018013055-0.51106810330976304250138606310485
    327022018015065-0.512509103701100346288158670330716
    34.58024020016070-0.513409804001180370308168710360849
    37.58524020018080-0.5145010404201270417345190770380951
    439526021020090-0.51596114646013964593852108204101546
    52100260220230100-0.51746123649015165214452409104502143
    60.5- 300240260120-0.519901990560173059050027010005003134
    68- 320250320150-0.523302330640201071462033011305705100

    Drawing of CB 3062 Type D Seven Tube Rollers Universal Fairleads with Upper Roller Ship Towing Equipment
