    GB 10106 Single Cross Bitt Cruciform Bollards with Plate Base Ship Mooring Equipment

    GB10106 Single Cross Bitt Cruciform Bollards with Plate Base Ship Mooring Equipment


    Description:

    GB 10106-88 ships cross bitts, adopting standard JIS F2804-76 for reference, have two types: type A and type B. Type A ship cross bitts is directly welded on the deck. While type B is welded on the deck liner.


    Main Technical Specification:
    1. Technical Standard: GB 10106-88 & JIS F2804-76
    2. Nominal Diameters: 150 to 350mm;
    3. Type: Type A & Type B
    4. Material: Mild Steel; Stainless Steel ;
    5. Weight: 31 to 204kg;
    6. Surface treatment: sandblasting to S2.5 + one layer of epoxy shop primer, Mirror or Satin Polished, Polished, Galvanized, customized surface treatment available.
    7. Classification Certificates:CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, Etc.

    Main Technical Parameter:

    Nominal
    Dia.

    Max.

    Breaking

    Load of

    Applicable

    Wire KN (tf)

    Steel Wire
    Rope

    Synthetic
    Fiber Rope

    Hmp

    Rope


    HBhDD1D2D3d

    Weight of

    Type A & B (Kg)

    150117(12)133044480460280168114206158240A31
    B33
    200225(26)19.54564560520320219168260210280A62
    B66
    250382(39)265680640610360273219310260340A98
    B105
    300549(56)3070104680660380325273360310400A143
    B153
    350686(70)34.577120720720420351273400314440A192
    B204

    Drawing of GB 10106 Ships Single Cross Bitt Cruciform Bollards with Plate Base Ship Mooring Equipment
