    Marine Electric Vertical Anchor Windlass Mooring Capstan Ship Deck Equipment

    Ask Lasest Price
    Brand Name : Zhongyuan
    Certification : CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA, Makers Test Certificate, Etc.
    Model Number : Standard and Customized
    Price : As per quotation
    Delivery Time : As per offer
    Payment Terms : TT, L/C, Etc.
    Supply Ability : Satisfy clients needs
    • Product Details
    • Company Profile

    Marine Electric Vertical Anchor Windlass Mooring Capstan Ship Deck Equipment

    Marine Electric Vertical Anchor Windlass Mooring Capstan Ship Deck Equipment


    Description:

    Vertical electric capstan windlass designed for small ship to hoisting anchor and mooring rope. It is widly used on coastal ship, inland waterway ship.


    Main Technical Specification:

    1. Working Load: 5KN to 250KN
    2. Type: Vertical or Horizontal
    3. Warping Speed(m/min):9-18m/Min
    4. Wire Rope Dia. 12.5- 46 (mm)
    5. Material: Stainless Steel (Polished), Mild Steel, Casting
    6. Power: Electric, Electric Hydraulic, Diesel Engine type
    7. Classification Certificates: CCS, NK, BV, ABS, DNV-GL, LR, KR, BKI, IRS, RS, Etc.

    Electric Anchor Capstan Parameters

    Chain GypsyWarping Head

    Motor Power

    (KW)

    Chain Dia. (mm)

    Load

    (KN)

    Speed

    (m/min)

    Warping Head Dia. (mm)

    Speed

    (m/min)

    12.57.51220010-184.5
    14111220010-185
    16151225010-187
    17.5171225010-189
    19191225010-1811
    2220.61230010-1811
    2424.51230010-1811
    2628.71230010-1811
    2833.31230010-1811
    3038.31235010-1818.5
    3243.51235010-1818.5
    3449.11235010-1822
    3655.11235010-1830
    3861.41235010-1830
    40681240010-1830
    22231240010-1811
    2427.41240010-1815
    2632.11240010-1818.5
    2837.21240010-1818.5
    3042.81250010-1822
    3248.61250010-1830
    3454.91250010-1830


    Drawing of Marine Electric Vertical Anchor Windlass Mooring Capstan Ship Deck Equipment
