    3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment

    Ask Lasest Price
    Brand Name : Zhongyuan
    Certification : CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA, Makers Test Certificate, Etc.
    Model Number : Standard and Customized
    Price : As per quotation
    Delivery Time : As per offer
    Payment Terms : TT, L/C, Etc.
    Supply Ability : Satisfy clients needs
    • Product Details
    • Company Profile

    3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment

    3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment


    Description:
    3Tx5m electric slewing crane: mainly used for ships and marine engineering to lift fuel, fuel, chemicals, garbage, food, spare parts and other items. The column is a seamless steel pipe for marine use. The lifting mechanism is composed of a marine lifting motor with brake and a gear box, and a slewing mechanism is composed of a slewing bearing and a reducer. The lifting arm adopts steel square box girder, and the electric control box is controlled by far and short range!

    Main Technical Specifications:

    1. Model: 3Tx5m electric slewing crane
    2. Lifting capacity: 3T
    3. Working radius: 5m
    4. Lifting speed: 6m/min
    5. Rotation speed: 0.8r/min
    6. Lifting motor power: 11kw
    7. Rotary motor power: 2.2kw
    8. Protection level: IP56
    9. Insulation class: Class F
    10. Control power supply: 24V safety voltage
    11. Power AC380V. 3 phases. 50HZ
    12. Working Temperature:-40 to 50℃ Etc.
    13. Surface treatment: sandblasting to S2.5 + 3 layers of epoxy paint,
    14. Classification Certificates:CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA.


    Main Technical Parameters:

    SWL
    (Ton)

    Working

    Radius
    (m)

    Slewing
    Speed
    (rpm)

    Hoisting

    Speed
    (m/min)

    Motor

    Power
    (kw)

    Pedestal Dia.
    (Φ mm)
     0.52-80.812 2.2/1.1 450
     0.82-100.712 2.2/1.5 530
     0.92-100.712 3.7/1.5 630
     12-100.712 3.7/1.5 680
     22-150.712 5.5/2.2 800
     32-150.612 7.5/3.7 900
     42-150.512 11/3.7 900
     52-150.512 15/5.5 1100

    Drawing of 3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment
